Zebra VC8300 10-INCH VEHICLE-MOUNTED COMPUTER

In stock

THE ULTIMATE UTRA-RUGGED ALL-TOUGH ANDROID VEHICLE MOUNT COMPUTER FOR THE WAREHOUSE

With your Windows-based vehicle mount computers near end-of-life and support for Windows-based mobile devices is ending, you’re ready to migrate to Android™. You need a rugged device that will make that migration and device management simple, easy and cost-effective. You need a keyboard to support your ‘green screen’ apps today, and a touchscreen to support the Android apps of tomorrow. And you need enterprise-class control of the Android operating system. Get it all with the VC8300.

Additional information

Features

Ready for the next generation of Warehouse Management Systems

Since the VC80x is based on Android, you’re ready for the new wave of Android-based Warehouse Management Systems (WMS). With a powerful computing platform and flexible development environment, the VC80x can grow as your applications evolve.

Built-in future proofing and operating system support

Only from Zebra, LifeGuard™ for Android guarantees direct security updates for a total of 10 years from the release date, along with the ability to upgrade to future versions of Android1 for a superior lifecycle and return on investment.

Android Certified for guaranteed security and performance

Since the VC80x is an Android Certified device, you get the peace of mind that comes from knowing the device is secure and proven compatible with the growing number of Android apps built for the warehouse and enterprise.

A common platform for the warehouse and beyond

If you are using Zebra Android handheld and wearable devices in the warehouse, workers and IT will benefit from a common operating system and solution platform. You’ll get the same user experience and management tools across different form factors throughout the warehouse and supply chain.

Specifications

CPU Qualcomm SnapdragonTM 660 octa-core 2.2 GHz
Memory 4 GB RAM/32 GB Flash pSLC
Operating System Android 11; upgradeable to Android 14
Software Ivanti Velocity (pre-loaded and pre-licensed)
Radio IEEE 802.11a/b/g/n/ac/k/r/d/h/i/v/w; IPv4, IPv6, 2×2 MU-MIMO
Data Rates
5GHz: 802.11a/n/ac—up to 866.7 Mbps
2.4GHz: 802.11b/g/n—up to 300 Mbps

Operating Channels
Channel 1-13 (2412-2472MHz): 1,2,3,4,5,6,7,8,9,10,11,12,13

Channel 36-165 (5180-5825 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency.

Security and Encryption
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES);WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES)— EAP-TTLS (PAP, MSCHAP, MSCHAPv2, GTC), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP, EAP-PWD; WPA Enterprise 192-bit (GCMP-256) — EAP-TLS; Enhanced Open (OWE)
FIPS 140-2 Level 1: Data in Motion and Data at Rest2

Multimedia Wi-Fi Multimedia (WMM and WMM-PS; Including TSPEC)
Certifications WFA (802.11n; 802.11ac; PMF, WMM-PS, WMM-AC, Voice Enterprise and Wi-Fi Direct)
Fast Roam PMKID caching, Cisco CCKM, OKC, 802.11r
WLAN Antennas Switchable internal or external antennas, various whip and magnetic mounted antennas available
Dimensions
10.87 in. W x 9.37 in. H x 3.54 in. D
276 mm W x 238 mm H x 90 mm D

Weight 8.2 lbs./3.7 kg
Display 10.4 in. color XGA (1024 x 768); 400 NITs
Touch Panel
Standard version: capacitive multi touch, Corning Gorilla Glass with air gap

Freezer version: resistive touchscreen with passive stylus or finger operation, integrated touchscreen heater evaporates external condensation

Power
12 to 48VDC nominal
10 to 60VDC min/max
Isolated and integrated power supply

Power Consumption
OFF: <1W

Suspend: 4 – 7.5W

Run Mode: 10-13W: display brightness at 50%, keyboard backlight off, Wi-Fi radio in receiving mode, and UPS battery fully charged.

36-40W: display brightness at 100%, keyboard backlight at 100%, Wi-Fi radio receiving and transmitting, UPS battery is charging, and scanner connected.61-65W: display brightness at 100%, keyboard backlight at 100%, Wi-Fi radio receiving and transmitting, UPS battery is charging, scanner connected and touch screen heater is on

UPS Heated Uninterruptable Power Supply (UPS); minimum 30-minute life over the full operating temperature range
Connectivity
1x Type C USB 3.0 combination host and client port; 1x USB 2.0 host port supports BC1.2; 1x standard powered USB 2.0 host port with 12V/1.5A; 2 x RS-232 COM ports with power on pin 9; 1 x 3.5 mm audio jack for push-to-talk speaker/mic.
All ports have strain relief and cover.

Scanner Support HID via USB and Bluetooth; SSI via USB and Bluetooth for DS/LI 36XX and RS6000; Serial RS232 with power on pin 9
Notifications
Indicators: audible tone
Power Status: green/amber LED
Warning: red LED
Blue key status: Blue LED

Voice and Audio
High volume 87 dBA speaker
External optional speaker/microphone

Keyboard Options Optional heated external QWERTY or AZERTY keyboard; optional keyboard mounting tray
Keys Six (6) programmable keys, volume/brightness, blue key for 2nd level functions, on/off key, diamond key (pops up on-screen keyboard)
Mounting RAM mount; quick release mount; U-mount; adapter for legacy vehicle computer mounts
Performance Characteristics

CPU Qualcomm SnapdragonTM 660 octa-core 2.2 GHz
Memory 4 GB RAM/32 GB Flash pSLC
Operating System Android 11; upgradeable to Android 14
Software Ivanti Velocity (pre-loaded and pre-licensed)
User Environment

Operating Temp. -22° F to 122° F/-30° C to 50° C
Storage Temp. -40° F to 140° F/-40° C to 60° C
Humidity 5% to 95% non-condensing (standard version); 5% to 95% condensing (freezer version with internal heating)
Sealing IP66
Impact Ball drop; 5 Joules on touchscreen; IEC EN 60079-15:2003
Shock/Vibration
IEC 60721-3-5M3; MIL-STD 810G; Method 514.6;
MIL-STD 810G; Method 516.6

Thermal Shock -22° F to 122° F/-30° C to 50° C
Integrated Sensors Gyroscope; Motion (Accelerometer); Temperature
Salt Fog 48h of 5% solution at 35° C
Solar Radiation EN/IEC 60068-2-5 solar radiation spectral energy distribution, 1120 W/m2 at display surface Environmental temperature: 40°C. Irradiation duration: 24 hours
Electrostatic
Discharge (ESD)

+/-20kV air discharge; +/-10kV contact discharge;
+/-10kV indirect discharge
