FootfallCam 3D Pro2 AI Vision People Counter with Dual 160° Fisheye Camera, PoE and Staff Exclusion

The FootfallCam Pro2 is an AI vision people counter for store and venue entrances, with a dual 5MP 160° fisheye camera, an octa-core processor and 8 TOPS NPU. The datasheet quotes accuracy of up to 99.5%. It mounts at 2.1 to 6.0 m, runs on PoE and includes AI staff exclusion.

WhatsApp for price
  • Authorised brands
  • Installation & training
  • AMC & repair support
  • Delivery across the GCC

Description

The FootfallCam Pro2 is the people counter FootfallCam positions for precise entrance measurement. Its datasheet quotes counting accuracy of up to 99.5%, bi-directional counting, real-time occupancy counting and counting with video proof.

Two 5MP cameras with a 160° field of view, plus a 5MP omni-vision module, are processed by an octa-core ARM processor with an 8 TOPS NPU. FootfallCam lists a 25-year MTBF for the device and made-in-the-UK manufacturing.

Coverage and mounting

One lens suits ceiling heights from 2.1 m to 6.0 m, and a coverage table in the datasheet gives entrance widths from 3.14 m at 2.1 m to 12.12 m at 6.0 m. Above 6 m, FootfallCam recommends a drop pole. The device works in low light down to 0.05 lux, and external infrared supports night-mode counting.

Staff exclusion

AI staff exclusion uses uniform cues, movement patterns and spatial likelihood models. FootfallCam states typical performance exceeds 90% in optimal conditions and may range from 60% to 90% where coverage or visual cues are limited, so entrance layout matters.

Build and connectivity

The aluminium oxide alloy casing with a 1 mm tempered glass lens cover is rated IP64 and described as splash proof. Power and data run over one Cat5e/Cat6 cable using IEEE 802.3at PoE at 15 W, and GPIO supports occupancy counting across entrances and exits.

Key features

  • Dual 5MP 160° fisheye cameras plus omni-vision module
  • AI video tracking with up to 99.5% datasheet accuracy
  • Octa-core ARM CPU, Mali GPU and 8 TOPS NPU
  • Bi-directional and real-time occupancy counting with video proof
  • AI staff exclusion (behaviour-based)
  • Mounting height 2.1 m to 6.0 m
  • IP64 aluminium casing, PoE (IEEE 802.3at)
  • GPIO and 1-year manufacturer warranty

Technical specifications

Product code (2025 datasheet) FC-F3DP12
Dimensions 154 (W) x 59 (D) x 40 (H) mm
Weight 0.4 kg (packed 0.86 kg)
Camera 2 x 5MP, 160°, plus 5MP omni-vision module
Frame rate / light 25 fps; minimum 0.05 lux
Processor ARM Cortex octa-core, ARM Mali GPU, 8 TOPS NPU, 4 GB memory
Mounting height 2.1 m to 6.0 m; maximum tilt 16°
IP rating IP64
Power PoE IEEE 802.3at, 48-56 VDC, 15 W, Cat5e/Cat6
Operating environment 10°C to 45°C, humidity 10% to 90%
Ethernet / interface 10/100 Mb Ethernet; HTTP, HTTPS
Data SQLite; csv, xml, txt reports; hourly upload to server
Warranty / origin 1 year; made in the UK

What’s in the box

FootfallCam’s datasheet does not list the kit contents. Mounting accessories and cabling depend on your site, so confirm the exact kit with our team before you order.

Ideal for

Retail stores, shopping malls, public buildings and transport venues that need accurate entrance counting and occupancy data.

Why buy the Pro2 from Technowave

Technowave has supplied Auto-ID and RFID technology across the UAE and GCC for more than 27 years. We can help you size coverage for each entrance. Tell us your entrances, ceiling heights and reporting needs, and our team will help you plan coverage and choose the right counters. Contact our team for a quote.
