Description
The Newland FM80 Salmon AI (NLS-FM8080V2-E-U30) is the AI version of Newland’s FM80 fixed-mount scanner, designed to sit inside self-service kiosks, self-checkouts, ticket gates and counters. Its large scan window lets customers present barcodes casually, even very close to the glass, and still get a fast read, which keeps queues moving when users are not trained.
Newland’s AI-powered detection and UIMG decoding read damaged, distorted and reflective codes, including mobile tickets and coupons shown on phone screens.
OCR for ID and document checks
Built-in OCR extracts text from IDs and official documents, which makes the FM80 Salmon AI a strong choice for age verification at self-checkouts, border and visitor management, library self-service and postal sorting. Digimarc reading is also supported.
Built into the checkout flow
A single-loop EAS antenna next to the window deactivates security tags from major systems such as Checkpoint as items are scanned. Advanced Sense Mode detects each presented code and opens one decode session for it, preventing accidental double reads, while six status indicators show decoding, configuration, communication and fault states at a glance.
Easy to mount and integrate
Six anchor points along the front edge and a soft inlay around the window help it fit cleanly into kiosk enclosures. It connects over USB or RS-232 and is configured with EasySet or Advanced Scripting.
Key features
- AI-powered barcode detection with Newland UIMG decoding
- 1280 × 1088 megapixel CMOS sensor and large scan window
- OCR for IDs and documents; Digimarc support
- Integrated EAS deactivation antenna (single-loop systems)
- Advanced Sense Mode prevents duplicate reads
- Six status indicators for quick feedback
- Six anchor points for kiosk mounting
- USB and RS-232 interfaces, 5-year warranty
Technical specifications
| Part number | NLS-FM8080V2-E-U30 |
|---|---|
| Image sensor | 1280 × 1088 CMOS, red LED illumination |
| Symbologies | Common 1D codes; PDF417, QR, Data Matrix, Aztec |
| Resolution / print contrast | ≥3 mil (1D) · 15% minimum |
| Depth of field | EAN-13 13 mil: 0–140 mm |
| Field of view | 42.4° horizontal × 36° vertical |
| Scan angle | Pitch ±50°, roll 360°, skew ±50° |
| Interfaces | USB-HID, USB-CDC, HID-POS, RS-232 |
| Power | 5 VDC ±5%; 280 mA typical, 800 mA max |
| Dimensions and weight | 149 × 78.5 × 166.5 mm · 455 g |
| Environment | IP52 · -20 °C to +50 °C operating |
| Warranty | 5 years standard |
What’s in the box
FM80 Salmon AI scanner, 3 m USB cable and EAS antenna.
Ideal for
Self-checkouts and retail kiosks, age-verification points, postal and parcel lockers, libraries, ticketing gates and government service desks.
Why buy the FM80 Salmon AI from Technowave
Technowave has supplied and supported Auto-ID and RFID technology across the UAE and GCC for more than 27 years. We help you choose the right configuration, set up and integrate the device with your ERP, WMS or POS, train your team and support it after go-live, including kiosk integration and EAS set-up. Protect your investment with our Newland AMC and repair service, or contact our team for a project quote and volume pricing.
