Description
The Newland WD3 is a wearable badge scanner about the size of an ID card. Staff wear it on the supplied neck lanyard or retractable belt clip, so both hands stay free until a barcode needs scanning, then simply point and press.
It pairs with Android mobile computers and phones over Bluetooth 5.0 and is ideal for picking, deliveries and stock counts where carrying a full handheld scanner is unnecessary.
Megapixel 2D scanning in a badge
A 1280 x 800 sensor reads high-density, damaged and on-screen 1D and 2D codes, including QR, DataMatrix and PDF417. Acuscan mode uses the red laser cross aimer so only the targeted barcode is decoded, even on a crowded picklist.
Works with or without a live connection
Batch mode stores scans in memory and uploads them later over Bluetooth or USB-C. Newland Android devices pair through the Nwear app, and third-party Android devices connect by scanning a QR code with the EasyConnect APK.
Tough enough for all-day wear
The WD3 has no moving parts, is IP65 sealed against dust and water and survives 1.2 m drops. Its 300 mAh battery lasts up to 8 hours and recharges in under 2 hours.
Key features
- Ultra-thin 53 g badge design with lanyard and belt clip
- Megapixel 1D/2D imager for paper and screen barcodes
- Acuscan precision aiming with red laser cross
- Bluetooth 5.0 (BLE and HID) up to 30 m, plus USB-C
- Batch memory for offline scanning
- IP65 sealing and 1.2 m drop rating
- Up to 8 hours battery life, under 2 hours to charge
Technical specifications
| Image sensor | 1280 x 800 CMOS, white LED illumination, 650 nm laser aimer |
|---|---|
| Field of view | 40° H x 25° V |
| Depth of field | EAN-13 (13 mil): 65-550 mm; QR (15 mil): 40-370 mm |
| Symbologies | 1D incl. Code 128, Code 39, EAN/UPC, GS1 DataBar; 2D incl. QR, DataMatrix, PDF417, Aztec, MaxiCode |
| Wireless | Bluetooth 5.0 (BLE, HID), up to 30 m in open space |
| Battery | 300 mAh Li-ion, up to 8 h use, under 2 h charge |
| Dimensions | 110.8 x 62.3 x 10.6 mm |
| Weight | 53 g |
| Sealing and drops | IP65; 1.2 m drop |
| Operating temperature | -20 °C to 60 °C |
| Warranty | 2 years |
What’s in the box
WD3 badge scanner (WD3-BS30), neck lanyard, retractable belt clip and USB-C cable. An NLS-DG-R USB Bluetooth dongle is available separately for PCs.
Ideal for
Warehouse picking and replenishment, last-mile delivery, retail stock counts and click-and-collect, healthcare and laboratory sample handling, and event or visitor check-in.
