Description
The Nordic ID Sampo S1, now sold under the Brady brand, is a simple but capable RAIN RFID reader and writer for desk and counter applications. Connect it to a Windows or Linux PC with one USB cable, which carries both data and power, and it is ready to read, encode and verify EPC Gen2 tags.
It completes the Sampo family on Technowave, alongside the Sampo S2 networked reader and the Sampo S0 antenna.
Long-range reading from a flat pad
The integrated 8 dBic circularly polarised antenna has an 80° beam and reads tags up to 5 m away, so one reader can cover a counter, a returns desk or a small doorway. Output power is adjustable in 1 dB steps up to 30 dBm (1 W ERP), letting you shrink the read zone for single-item encoding or widen it for bulk counts.
Fast, reliable multi-tag reads
Dense reader mode handles around 200 tags at once, which suits checking in a tote of tagged assets, verifying a carton of garments or auditing library returns. A light sensor and a tapping sensor can trigger reads, and a buzzer plus power, RF and read LEDs give feedback.
Quick to integrate
The Sampo S1 works with Windows 10, 8 and 7 and Linux, and Brady’s RFID demo app covers inventory, tag writing and locating out of the box. It runs from USB power or from the optional 110–240 V AC adapter.
Key features
- USB 2.0 connection for both data and power
- Integrated 8 dBic circularly polarised antenna, 80° beam
- Read range up to 5 m
- Output adjustable in 1 dB steps, max 30 dBm (1 W ERP / 1.6 W EIRP)
- Around 200 tags in dense reader mode
- Light and tap sensors to trigger reads
- EPC Class 1 Gen2v2 (ISO 18000-63, RAIN) read and write
- Works with Windows and Linux
Technical specifications
| Part number | SAMPOS1-RDR (article 310215), EU frequency, USB |
|---|---|
| Air protocol | ISO 18000-63, EPC Class 1 Gen2v2 (RAIN RFID) |
| RF output | 27 dBm (500 mW) default, adjustable in 1 dB steps, max 30 dBm (1 W) ERP / 1.6 W EIRP |
| Receive sensitivity | -70 dBm |
| Antenna | Integrated 8 dBic circular polarised, 80° beam width |
| Read range | Up to 5 m |
| Reading speed | 200 tags in DRM mode |
| Interface | USB 2.0 (mini USB connector) |
| Power | USB power or AC adapter, 110–240 V |
| Operating systems | Windows 10, 8, 7; Linux |
| Dimensions / weight | 200 × 25 × 260 mm · 540 g |
| Environment | Operating -20°C to 55°C · storage -40°C to 85°C · IP20 |
| Warranty | 2 years |
What’s in the box
Sampo S1 reader. The AC adapter, USB cable and external antennas are configuration dependent or sold separately; please confirm with our team.
Ideal for
Retail and fashion counters, RFID label encoding and verification stations, library check-in, asset and tool rooms, inventory and inspection labelling, and laundry or uniform handling.
Why buy the Sampo S1 from Technowave
Technowave has supplied and supported Auto-ID and RFID technology across the UAE and GCC for more than 27 years. We help you choose the right configuration, set up and integrate the device with your ERP, WMS or POS, train your team and support it after go-live, including RFID tag selection and PC application integration. Protect your investment with our annual maintenance contract (AMC), or contact our team for a project quote and volume pricing.
