Description
The Zebra ZC10L is a direct-to-card printer for large-format cards. Instead of printing a standard ID card and inserting it into a holder, it prints a full-colour, edge-to-edge 140 x 88 mm card in one step, ready to hand to a guest, delegate or fan.
Organisers of concerts, sporting events, conferences and festivals use it to produce eye-catching credentials on demand, and hotels and venues use it for branded key cards and passes.
Edge-to-edge colour in one pass
Dye-diffusion printing at 300 dpi produces photo-quality images right to the edge of the card. Single-sided colour cards print at up to 195 cards per hour and black monochrome at 360-410 cards per hour, so on-site badge desks keep up with arrivals.
Smart, secure credentials
Cards are 24 mil PVC and can include HF, UHF or dual HF/UHF smart chips for access control and cashless payments. Zebra’s intelligent ribbon technology authenticates genuine ribbons and tracks remaining prints automatically.
Easy to run at any venue
A 200-card feeder, 70-card output hopper and multi-status LED display keep operation simple. It connects by USB, with Ethernet via an external print server, and Zebra CardStudio 2.0 design software is included as a 30-day trial.
Key features
- Prints oversized 140 x 88 mm (5.5 x 3.46 in.) cards and badges
- Full-colour, edge-to-edge printing in a single pass
- Up to 195 colour or 360-410 monochrome cards per hour
- 300 dpi photo-quality output
- HF, UHF and dual HF/UHF smart card options
- 200-card feeder and 70-card output hopper
- USB standard; Ethernet via external print server
Technical specifications
| Print method | Direct-to-card dye diffusion, single-sided, colour or monochrome |
|---|---|
| Print speed | Up to 195 cards/hour (colour); 360-410 cards/hour (black) |
| Resolution / memory | 300 dpi; 64 MB |
| Card size | 140 x 88 mm (5.5 x 3.46 in.), 24 mil PVC |
| Smart cards | HF, UHF, dual HF/UHF |
| Capacity | 200-card feeder, 70-card output hopper |
| Ribbons | YMCO 400 images/roll; black monochrome 2,000 images/roll |
| Interfaces | USB 2.0; 10/100 Ethernet via external print server |
| Dimensions | 290 x 278 x 485 mm (H x W x D) |
| Weight | 21 kg |
| Operating environment | 10 °C to 35 °C, 20-80% RH non-condensing |
| Warranty | 1 year from shipment |
What’s in the box
ZC10L printer with power supply, USB cable, Windows drivers and a CardStudio 2.0 trial licence. Cards and ribbons are ordered separately; we can supply both.
Ideal for
Concerts, festivals and sports events, conferences and exhibitions, VIP and backstage passes, hotel and resort key cards, and venues that issue large, branded credentials on site.
