Description
The Honeywell Xenon Ultra 1960g is the latest generation of Honeywell’s popular Xenon family of handheld imagers. Designed for retail checkouts, pharmacies, logistics counters and light manufacturing, it reads printed labels, poor-quality and damaged barcodes, and codes on smartphone screens quickly and reliably.
A green-dot LED aimer makes targeting easy, and infrared object detection wakes the scanner automatically when an item is presented, so it works equally well handheld or in a presentation stand.
Built for speed at the counter
Motion tolerance of up to 4 m/s on 13 mil UPC codes means items can be swiped quickly without missed reads, keeping queues moving. The scanner performs in lighting from total darkness up to 100,000 lux, and reads codes with as little as 15% print contrast.
Tough enough for daily use
The 1960g is engineered to survive 50 drops from 1.8 m to concrete and 2,000 tumbles, and is sealed to IP52 against dust and splashes. A 5-year warranty reflects that durability.
Easy to deploy and manage
USB, RS-232 and keyboard-wedge interfaces connect it to virtually any POS or PC, and Honeywell Scanner Management Utility (SMU) lets IT teams configure and update scanners remotely.
Key features
- Area-imaging 1D/2D scanner, standard range (SR); high-density version available
- Reads damaged, low-contrast and mobile-screen barcodes
- Motion tolerance up to 4 m/s (SR, 13 mil UPC)
- Green-dot LED aimer and IR object detection
- Works handheld or hands-free in a stand
- 50 × 1.8 m drops and 2,000 tumbles; IP52
- USB, RS-232 and keyboard-wedge interfaces
- 5-year standard warranty
Technical specifications
| Part number | 1960GSR-2USB-N (standard range, USB kit) |
|---|---|
| Scan pattern | Area image, 1D and 2D |
| Motion tolerance | SR: 4 m/s · HD: 3.4 m/s (13 mil UPC at optimal focus) |
| Ambient light | 0 to 100,000 lux |
| Aimer | Green-dot LED |
| Interfaces | USB, RS-232, keyboard wedge |
| Operating power | 2.5 W (500 mA @ 5 V DC) |
| Dimensions | 108.2 × 70.4 × 160.2 mm |
| Drop / tumble | 50 × 1.8 m drops to concrete · 2,000 × 0.5 m tumbles |
| Sealing | IP52 |
| Operating temperature | 0°C to 50°C |
| Warranty | 5 years |
What’s in the box
Xenon Ultra 1960g scanner with USB cable (kit).
Ideal for
Retail and supermarket checkouts, pharmacies, healthcare counters, logistics and parcel counters, and light manufacturing.
Why buy the Xenon Ultra 1960g from Technowave
Technowave has supplied and supported Auto-ID and RFID technology across the UAE and GCC for more than 27 years. We help you choose the right configuration, set up and integrate the device with your ERP, WMS or POS, train your team and support it after go-live. Protect your investment with our Honeywell AMC and repair service, or contact our team for a project quote and volume pricing.
