SD100 Orion Plus – 5G Rugged Tablet

In stock

Speedata

Say hello to our first 5G Android tablet for all your 1D and 2D scanning needs. This 10.1-inch robust tablet makes for the ultimate scanning companion from the shop to the stock floor.







Data sheet



Category:

The SD100 Orion Plus boasts a suite of advanced technical specifications designed to elevate efficiency and ensure future readiness:

Processor and Operating System: The device comes equipped with a high-performance processor that effortlessly manages extensive data processing tasks. Additionally, it supports the latest Android operating systems, ensuring seamless compatibility with modern applications and up-to-date security features through 2025.

5G Compatibility: Engineered for the future, the SD100 Orion Plus supports 5G technology, which significantly enhances data transmission speeds and connectivity. This feature is essential for real-time data processing and supporting cloud-based operations within business environments.

Robust Wireless Connectivity: Beyond 5G, the device also incorporates advanced wireless technologies, including Wi-Fi and Bluetooth 5.0. These features significantly enhance the device’s ability to maintain stable and fast connections across a variety of operational settings.

Security Features: The SD100 Orion Plus is fortified with the latest security protocols, safeguarding sensitive data against unauthorized access. This includes cutting-edge encryption standards and secure boot features, ensuring comprehensive data protection.

Extended Battery Life: The device is powered by a robust battery, designed to support extended operational hours and minimize downtime. This is crucial in high-demand environments, boosting productivity and ensuring continuous performance.

With these capabilities, the SD100 Orion Plus stands out as a highly capable tool, tailored for businesses that demand reliability, speed, and security.



Product Specifications : SD100 Orion Plus

Category Feature Specification
Data Capture 1D All major 1D symbologies
2D All major 2D symbologies
Performance Operating System Android 11 GMS (AER)
Processor Octa-core 2.2GHz
Memory RAM 4GB
Memory Flash 64GB
Physical Audio Front dual stereo speakers, Volume 90db±3db (test distance 10cm)
Audio Jack 3.5mm earphone jack
Battery Type 9000mAh
Camera Rear 13MP AF, high brightness LED flash, front 5MP camera
Dimensions (mm) 254 x 176 x 17.4 mm
Display 10” (1200×1920) IPS highlight screen
Expansion Slot 2 Micro SIM card slots, 1 SD card slot
Expected Battery Life Typical working time not less than 10 hours
Expected Charge Time Fast charging, full charging time < 4 hours
Interfaces USB Type-C
Touch Panel 5-point capacitive touch screen
Wireless WWAN RADIO FDD-LTE B1/B3/B5/B7/B8, TDD-LTE B38/B39/B40/B41, TDSCDMA B34/B39, WCDMA B1/B2/B5/B8, GSM B2/B3/B5/B8, CDMA 1 x/CDMA2000 BC0/BC1
WLAN RADIO IEEE 802.11 a/b/g/n/ac 2.4G 5G dual frequency
WPAN RADIO Bluetooth 5.1 BLE
GPS GPS+BD+GLONASS
Environmental Operating Temperature -20°C to 55°C
Storage Temperature -30°C to 70°C
Humidity 5%-95% (non-condensing)
ESD ± 15kV air discharge, ±8kV contact discharge
Drop 1 meter drop to cement floor
Certifications & Warranty IP Rating IP65
Hardware Certifications CCC, CE
Warranty Standard 2 years
