Description
The Zebra FXR90 is built for RFID read points where ordinary readers fail: outdoor gates and yards, loading docks exposed to weather, cold stores, wash-down production lines and vehicles. Sealed to dual IP65 and IP67 ratings with rugged M12 connectors, it keeps tracking assets, pallets and returnable containers in dirt, moisture and temperature extremes.
With a maximum read rate of more than 1,300 tags per second and higher receiver sensitivity, the FXR90 delivers fast, accurate inventory and asset visibility across large transportation, logistics, warehousing and manufacturing sites.
Deploy without running cables
The integrated RFID antenna allows simple, cable-free installation, while 4 external antenna ports (8-port models available) maximise the read zone for portals and dock doors. Wi-Fi, 5G cellular and CBRS options mean you can install readers in remote areas without pulling Ethernet.
Flexible power and mounting
Power the FXR90 with PoE/PoE+, an IP67-sealed AC/DC or DC/DC supply, or wire it directly to an electrical panel or vehicle battery. Flush and articulating VESA mounts are included for walls, poles and vehicles.
Easy to configure and manage
A mobile-friendly web interface and Bluetooth 5.3 let installers configure readers from almost any Android or Windows device, and Zebra IoT Connector streams tag data to cloud and enterprise systems using standard IoT protocols, with no coding required.
Key features
- Ultra-rugged dual IP65/IP67 housing with sealed M12 connectors
- 1,300+ tags per second with high receiver sensitivity
- Integrated RFID antenna plus 4 external antenna ports
- Gigabit Ethernet, Wi-Fi 6, Bluetooth 5.3; 5G, GPS and CBRS on cellular models
- PoE/PoE+, sealed AC/DC, DC/DC or direct-wire power options
- 4 inputs / 4 outputs GPIO for lights, sensors and gates
- Linux OS with Zebra IoT Connector and web-based management
- Flush and VESA mounting included
Technical specifications
| Part number | FXR90001-400000-WR (4 ports, integrated antenna, worldwide UHF 800/900 MHz) |
|---|---|
| Air protocol | EPC Gen2 UHF RAIN RFID |
| Frequency / output (integrated antenna) | EU: 865–868 MHz, 0–33 dBm ERP · US: 902–928 MHz, 0–36 dBm EIRP (region dependent) |
| Max read rate | 1,300+ tags/second |
| Antenna ports | 4 external (8-port models available) + integrated antenna |
| Network | Gigabit Ethernet, Wi-Fi, Bluetooth 5.3; 5G, GPS, CBRS on WWAN models |
| I/O | 2 × USB host, USB client, 4 GPIO inputs / 4 outputs |
| Processor / OS / memory | NXP i.MX8 Mini quad Cortex-A53 · Linux · 2 GB RAM / 16 GB eMMC |
| Power | PoE (802.3af), PoE+ (802.3at), sealed AC/DC or DC/DC supply, direct wire |
| Sealing | IP65 and IP67 |
| Dimensions / weight | 33.5 × 25.4 × 5.5 cm with flush-mount brackets · approx. 3.07 kg (integrated antenna model) |
| Security | TLS 1.2/1.3, FIPS 140-2 |
What’s in the box
FXR90 reader with flush and VESA mounting hardware. Power supply, PoE injector and external antennas are sold separately.
Ideal for
Yard and gate management, dock-door and portal reads, cold-chain and wash-down areas, vehicle-mounted reading, returnable asset tracking and manufacturing work-in-progress.
Why buy the FXR90 from Technowave
Technowave has supplied and supported Auto-ID and RFID technology across the UAE and GCC for more than 27 years. We help you choose the right configuration, set up and integrate the device with your ERP, WMS or POS, train your team and support it after go-live, including RFID site surveys, antenna planning and middleware integration. Protect your investment with our Zebra AMC and repair service, or contact our team for a project quote and volume pricing.
